Basic specifications:
- Diameter of screw: 5mm*2
- Screw L/D length: 30:1
- Screw Speed:5-65r/min
- Power of main motor:15kw
- Max output:80kg/h
- Max folding width of film:200-1200mm
- Single-sided thickness of film:0.008-0.15mm
- Thicness tolerance: ±8%
- Weight of machine:3200kg
- Overall dimensions: 4800*3000*6500(mm)
- Power: 380v/3p/50hz
Extruder: 55/30×2
- Screw diameter: Φ55mm, L/D 30:1
- Screw material: 38 CrMoala with alloy
- Cylinder material: 38 CrMoala
- Screw heating: Cast aluminum heating coil
- Cylinder cooling: feeding part forced water cooling, working part of air cooling
- Main motor: 15kw (Weinuo, Nanjing, China)
- Inverter: 15kw, (Denmark, Danfoss )
- Gearbox: 146 type, Hard tooth surface gear (Hangzhou, China)
Die head
- Die type: double co extrusion
- Die diameter: Φ250mm
- Die auto thermos control: 2 points
- Die head heating: Cast aluminum heating coil
- Die heater capacity: 2.5kw
- Air blower: 3kw
FAQ:
Q:Are you factory or trading company?
A: We are factory and manufacture.
Q: Where is your factory located? How can I visit your factory?
A: We are located in wenzhou, you can fly to wenzhou airport. We can pick you up from the airport to your hotel.
Q:How to place my order?
A: Just contact our Trader Manager, E-mail, WhatsApp,Skype or telephone to confirm the product, make the deposit then we will start to manufacture.
Q:Can you offer some video or pictures of the Q packing machine?
A:Yes, of course. Besides, we can help you to have your products packaging if you are available to send us some of your product and then record a video for your reference.
Q:When can I get my machine after I paid?
A:The delivery time is based on the exact machine you confirmed.
Q:Can you design the machine according to our requirements?
A:Yes. We not only can customize the machine according to your technical drawing, but also can make new machine according to your requirements.
Q:Can you offer overseas technical support?
A:Yes. We can send engineer to your company to set the machine and train your
worker if needed.
